Salt spray fog test chamber for corrosion resistance test

FOB Reference Price:Get Latest Price
$800.00 - $1,000.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 5 >5
Est. Time(days) 900 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Sailham
Model Number:
ZH-SH-60
Power:
Electronic
Product name:
Salt spray fog test chamber
Certificate:
ISO9001:2008 CE FCCA
Power supply:
AC220V
Temperature range:
RT+10℃~55℃
Humidity range:
≥93%R.H
Temperature uniformity:
±2℃
Internal dimensions:
600*450*400(mm)
Fog deposition:
1~2ml/80c㎡
Spray mode:
Continuous/periodic option
Weight:
60kg
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Packaging Details
1. Outside package: Sandard export wooden cases
2. Inner package: Stretch film
Port
Shenzhen port,Guangzhou port
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 900 To be negotiated
Video Description

Corrosion test salt spray equioment for metal/rubber/hardware



Product Description


Salt Spray chambers are commonly used to evaluate the corrosive properties of:
Phosphated surfaces (with subsequent paint/primer/lacquer/rust preventive).
Zinc and Zinc-alloy plating (see also electroplating).
Electroplated chromium, nickel, copper and tin.
Coatings not applied electrolytically (such as zinc flake coatings).
Organic Coatings.
Paint Coating.







Specification parameter list:

Model

ZH-FQY-60

ZH-FQY-90

ZH-FQY-120

ZH-FQY-160

ZH-FQY-200

Inner box size:
(L×W×H) cm

60×45×40

90×60×50

120×100×50

160×100×50

200*100*50

Outside box size:
(L×W×H)cm

108*108*65

135×112×75

190×128×125

230×128×125

270*128*125

Temperature range

35℃~55℃;

Test chamber temperature

NSS ACSS 35℃±1℃(CASS 50℃±1℃)

Saturated air barrel temperature

NSS ACSS 47℃±1℃(CASS 63℃±1℃)

Temperature fluctuations

≤±0.5°C

Temperature uniformity

≤±2.0°C

Lab volume

110L

270L

600L

800L

1000L

Brine tank capacity

15L

25L

40L

65L

80L

Multiple safety protection devices

Water shortage; over temperature ;phase protection

Standard accessories

Test salt, measure bucket, tool etc 1 set

weight (kg)

60

90

180

280

450

Power

AC220V 1Φ20A

AC220V 1Φ20A

AC220V 1Φ30A

AC380V 3Φ15A

AC380V 3Φ15A





Features

1. The  salt spray test chamber. Completely self contained, the MX series salt spray chamber allows for test items to be subjected to a corrosive environment without introducing other contaminants into the test area.

2. The standard MX salt spray test chamber is compliant with ASTM-B117, MIL-STD-202F, MIL-STD-750B, MIL-STD-810D standards for corrosion testing and can be modified to meet MIL-STD-883C and MIL-STD-19500.
